ProArt X870E-Creator WiFi Motherboard

Processor and Memory

• Chipset: AMD X870E
• CPU Support: AMD Socket AM5 for Ryzen™ 9000, 8000, 7000 Series Desktop Processors
• Memory: 4 x DIMM slots, up to 192GB DDR5
  • Overclocking up to 8000+ MT/s with Ryzen™ 9000, 8000, and 7000 Series Processors
  • Dual-channel memory architecture, ECC and Non-ECC unbuffered DIMM support
  • Supports AMD Extended Profiles for Overclocking (EXPO™) and ASUS Enhanced Memory Profile (AEMP)

Graphics and Expansion Slots

• Graphics Outputs:
  • 1 x HDMI™ 2.1 port (supports 4K@60Hz)
  • 2 x USB4® (40Gbps) ports supporting USB Type-C® display outputs (up to 8K@60Hz)
• Expansion Slots:
  • Ryzen™ 9000 & 7000 Series: 2 x PCIe 5.0 x16 slots (supports x16, x8/x8, or x8/x4/x4 modes)
  • Ryzen™ 8700/8600/8400 Series: 1 x PCIe 4.0 x16 slot (supports x8 mode)
  • Ryzen™ 8500/8300 Series: 1 x PCIe 4.0 x16 slot (supports x4 mode)
  • Chipset Slots: 1 x PCIe 4.0 x16 slot (supports x4 mode)

Storage and Connectivity

• Storage:
  • 4 x M.2 slots (varies by processor support, PCIe 5.0 and PCIe 4.0)
  • 4 x SATA 6Gb/s ports
  • Supports AMD RAIDXpert2 Technology for PCIe and SATA RAID 0/1/5/10 (RAID 5 only with Ryzen™ 9000 series)
• Ethernet:
  • 1 x Marvell® AQtion 10Gb Ethernet
  • 1 x Intel® 2.5Gb Ethernet with ASUS LANGuard
• Wi-Fi & Bluetooth:
  • Wi-Fi 7 (802.11be), 2x2 support for 2.4/5/6 GHz bands
  • Bluetooth® v5.4

USB Ports

• Rear USB (Total 11 ports):
  • 2 x USB4® (40Gbps, USB Type-C®)
  • 1 x USB 20Gbps (USB Type-C®)
  • 7 x USB 10Gbps (Type-A)
  • 1 x USB 2.0 (Type-A)
• Front USB (Total 9 ports):
  • 1 x USB 20Gbps (USB Type-C®, supports up to 30W PD/QC4+)
  • 1 x USB 5Gbps header (supports 2 USB 5Gbps ports)
  • 3 x USB 2.0 headers (supports 6 additional USB 2.0 ports)

Audio Features

• Audio Codec: Realtek ALC1220P 7.1 Surround Sound High Definition Audio CODEC
  • Impedance sense, internal audio amplifier, support for up to 32-Bit/192 kHz playback
  • Supports jack-detection, multi-streaming, and front panel jack-retasking

Cooling and Power

• Cooling Headers:
  • 1 x 4-pin CPU Fan header, 1 x 4-pin CPU OPT Fan header
  • 1 x 4-pin AIO Pump header, 5 x 4-pin Chassis Fan headers
• Power:
  • 1 x 24-pin Main Power connector
  • 2 x 8-pin +12V CPU Power connectors

Special Features

• ASUS 5X Protection III:
  • DIGI+ VRM, Enhanced DRAM Overcurrent Protection, ESD Guards, LANGuard, Overvoltage Protection, SafeSlot
• ASUS Q-Design:
  • PCIe Slot Q-Release Slim, M.2 Q-Latch, M.2 Q-Release, Q-LED indicators, Q-Slot
• ASUS Thermal Solution:
  • M.2 heatsinks, VRM heatsink
• ASUS EZ DIY:
  • BIOS FlashBack™ button, pre-mounted I/O shield
• AURA Sync: Addressable Gen 2 headers for RGB syncing

Software Features

• ASUS Exclusive Software:
  • Armoury Crate (Aura Creator, Aura Sync, Fan Xpert 4 with AI Cooling II)
  • USB Wattage Watcher, ASUS DriverHub, GlideX
  • UEFI BIOS EZ Mode, ASUS CrashFree BIOS 3, ASUS EZ Flash 3
• Bundled Software:
  • ProArt Creator Hub, Adobe Creative Cloud (Trial), Norton 360 Deluxe (60 Days Trial), WinRAR (40 Days Trial)

Accessories Included

• Cables and Connectors:
  • 1 x DisplayPort cable, 4 x SATA 6Gb/s cables, 1 x ASUS WiFi Q-Antenna
  • 1 x Q-connector, M.2 Q-Latch packages, rubber packages for M.2 slots
  • 1 x ProArt ruler
• Documentation:
  • Quick start guide, ACC Express Activation Key Card

Form Factor

• ATX Form Factor: 12 inch x 9.6 inch (30.5 cm x 24.4 cm)
• Operating System: Windows® 11 support
