RM1000x SHIFT Fully Modular ATX Power Supply
- $282.24
- $288.00
| CORSAIR RM1000x SHIFT Fully Modular ATX Power Supply | |
|---|---|
| Model | RM1000x SHIFT |
| Part Number | CP-9020300-NA |
| Product Type | Fully Modular ATX Power Supply |
| Continuous Power Output | 1000W |
| ATX Standard | ATX 3.1 |
| PCIe Standard | PCIe 5.1 compliant |
| Efficiency Certification | Cybenetics Gold |
| Noise Certification | Cybenetics A |
| AC Input Voltage | 100V–240V AC; 200V–240V for Korea and India configuration |
| Input Current | 12A–6.5A; 10A for 200V–240V configuration |
| Input Frequency | 47Hz–63Hz |
| +3.3V Rail | 20A |
| +5V Rail | 20A |
| Combined +3.3V / +5V Output | 120W maximum |
| +12V Rail | 83.3A / 1000W |
| +5VSB Rail | 3A / 15W |
| Modular Design | Fully modular CORSAIR Type-5 connectors with side-mounted SHIFT cable interface |
| ATX Motherboard Connector | 1x 24-pin modular cable |
| CPU / EPS Connectors | 2x EPS12V 4+4-pin cables |
| PCIe Power Connectors | 2x PCIe 6+2-pin cable connectors, plus the included 12V-2x6 cable options |
| GPU Power Cable | 1x 90° 12V-2x6 to 600W 12V-2x6 (12+4-pin) modular cable |
| Alternative GPU Cable | 1x 600W 90° 12V-2x6 to dual PCIe 6+2-pin cable |
| SATA Connectors | 12 total connectors across 4 modular cables, with 3 connectors per cable |
| PATA / Peripheral Connectors | 4 connectors on 1 modular cable |
| 24-pin ATX Cable Length | 610mm ±10mm |
| EPS Cable Length | 650mm ±10mm per cable |
| PCIe Cable Length | 650mm ±10mm per cable |
| 12V-2x6 Cable Length | 650mm ±10mm per cable |
| SATA Cable Length | 700mm ±10mm; connector spacing 500mm, 100mm, 100mm |
| PATA Cable Length | 750mm ±10mm; connector spacing 450mm, 100mm, 100mm, 100mm |
| Cable Type | Type-5 modular cables; debossed PVC cable kit |
| Cooling Fan | 140mm fan with Fluid Dynamic Bearing (FDB) |
| Zero RPM Mode | Yes, for near-silent operation at low to medium loads |
| Manual Fan Control | Fan speed override knob |
| Capacitors | 100% industrial-grade Japanese electrolytic capacitors rated at 105°C |
| Continuous Operating Temperature | Up to 50°C |
| Modern Standby | Yes |
| MTBF | 100,000 hours |
| Dimensions | 160 x 150 x 86mm |
| Required Side Clearance | Approximately 30mm between PSU and case side panel for access to SHIFT connectors |
| Weight | Approximately 3.10kg |
| Warranty | 10 years |
