NZXT H5 Flow Tempered Glass White Casing
Pre-Order- $134.00
H5 Flow Compact Mid-tower Airflow Case - White
The H5 Flow features a perforated front panel to generate an extra dimension of airflow for maximum cooling potential. With optimized thermal performance and intuitive cable management, the H5 Flow is an ideal chassis for most builds.
Dedicated fan on bottom inside panel is angled to cool GPU
Perforated front panel provides optimal ventilation
Intuitive cable management system with wide channels, hooks, & straps
Tool less access to front and side panels
Front panel supports up to 2 x 140mm fans or 280mm radiator
Top panel supports up to 2 x 120mm fans or 240mm radiator
Includes two pre-installed F120Q fans
This product is out of stock, submit your email and we will update once it restock.
DIMENSIONS
Height: 464mm (With Feet)
Width: 227mm
Depth: 446mm
Weight: 7.01 kg
COMPATIBILITY & CLEARANCE
Max CPU Cooler Clearance: Up to 165mm
Max GPU Clearance: Up to 365mm
Front Radiator Clearance: 45mm
Cable Management: Up to 23mm
FRONT I/O PORTS
USB 3.2 Gen 1 Type-A: 1
USB 3.2 Gen 2 Type-C: 1
Headset Audio Jack: 1
EXPANSION SLOTS
Standard: 7
Vertical: 0
DRIVE BAYS
2.5": 1+1
3.5": 1
FAN SUPPORT
Front: 2 x 120mm / 2 x 140mm
Top: 2 x 120mm
Rear: 1 x F Series Quiet 120mm (Case Version) included
Bottom: 1 x F Series Quiet 120mm (Case Version) included
RADIATOR SUPPORT
Front: Up to 280mm
Top: Up to 240mm
Rear: Up to 120mm
FAN SPECS
Model: F120Q (Case Version)
Speed: 1200 ± 240RPM
Airflow: 62.18 CFM
Static: 1.05 mm - H2O
Noise: 25.1 dBA
Fan Connector: 3-pin
| NZXT H5 Flow Tempered Glass White Casing | |
|---|---|
| Enclosure Type | Mid-Tower |
| Motherboard Support | E-ATX (Up to 277 mm wide), ATX, Micro-ATX, Mini-ITX |
| Case Material | SGCC Steel, Ultra-Clear Tempered Glass |
| Dimensions | 465 mm (H) x 225 mm (W) x 430 mm (D) |
| Weight | 7.28 kg |
| Expansion Slots | 7 Standard |
| Drive Bays | 2 x 2.5 inch, 1 x 3.5 inch |
| Maximum GPU Length | 410 mm |
| Maximum CPU Cooler Height | 170 mm |
| Maximum PSU Length | 200 mm |
| Front Panel I/O | 1x USB 3.2 Gen 2x2 Type-C, 1x USB 3.2 Type-A, 1x Headset Audio Jack |
| Radiator Compatibility | Up to 360 mm (Front), Up to 240 mm (Top - 280 mm with low-profile memory) |
| Fan Support | Up to 3x 120 mm / 2x 140 mm (Front), 2x 120 mm / 2x 140 mm (Top), 2x 120 mm (Bottom), 1x 120 mm (Rear) |
| Included Fans | 2x F120Q (Case Version) |
| Warranty | 2 years |
