MSI B860 GAMING PLUS WIFI ATX Motherboard Specifications
Chipset	Intel B860
Socket	LGA 1851
CPU Support	Intel Core Ultra Processors (Series 2)
Form Factor	ATX
Memory Type	DDR5 (Dual Channel)
Memory Speed	8800+ MT/s (Overclocked)
Memory Features	XMP Profiles, Memory Boost, Memory Extension Mode
M.2 Storage Slots	3 M.2 Connectors (Lightning Gen 5 x4 M.2 Support)
M.2 Cooling	EZ M.2 Shield Frozr II, Tool-Free EZ M.2 Clip II
Primary PCIe Slot	PCIe 5.0 x16 with Steel Armor Reinforcement
GPU Retention	EZ PCIe Clip II
PCIe Supplemental Power	Dedicated PCIe Power Connector for High-Power GPUs
VRM Design	12+1+1+1 Duet Rail Power System with P-PAK
CPU Power Connectors	8+4-pin CPU Power
Power Features	Core Boost
PCB Construction	6-Layer Server-Grade PCB
Thermal Management	7W/mK Thermal Pads, Extended Heatsink, Enlarged Chipset Heatsink, VRM Heatsink
Fan Headers	Combo Fan/Pump Header (Auto-Detect), Dedicated Pump Fan Header, EZ Conn JAF_1
LAN	Intel Killer 5G LAN
Wi-Fi	Intel Killer Wi-Fi 7 (Up to 5.8 Gbps)
Antenna	EZ Antenna with Magnetic Stand
Thunderbolt	Thunderbolt 4 Port (Up to 40 Gbps)
USB Type-C	Front USB Type-C Header
Audio	Audio Boost with High-Quality Capacitors, Isolated Audio Structure, De-Pop Protection
RGB Lighting	ARGB Headers (A-RAINBOW V2), RGB Headers, Ambient Link, Mystic Light Control
Diagnostics	EZ Debug LED, EZ Memory Detection LED, Clear CMOS Button, Flash BIOS Button
DIY Features	Pre-Installed I/O Shield, Stainless Steel I/O Shield
BIOS	Click BIOS X

Quantity

Share Now

Out of Stock!

This product is out of stock, submit your email and we will update once it restock.

» Next-Gen Processing: Engineered for Intel® Core™ Ultra Processors (Series 2) utilizing the LGA 1851 socket and INTEL B860 chipset with a robust 12+1+1+1 Duet Rail Power System.
» High-Speed Memory: Supports up to 256GB of DDR5 memory with blazing speeds up to 8800+ MT/s (OC), fully compatible with Intel® XMP 3.0 and CUDIMM.
» Lightning Connectivity: Features ultra-fast Intel® Killer™ 5G LAN, cutting-edge Wi-Fi 7, Bluetooth 5.4, and Thunderbolt™ 4 connectivity.
» Robust Storage Options: Equipped with 3x M.2 slots (including one PCIe 5.0 x4 slot for maximum bandwidth) alongside 4x SATA 6G ports with RAID support.

• PCIe 5.0 x16: 1x Slot (PCI_E1 supports up to x16 from CPU)
• PCIe 4.0 x16: 3x Slots (PCI_E3 supports up to x4, PCI_E2 & PCI_E4 support x1 via Chipset)

• M.2 Slots: 3x total (M.2_1 PCIe 5.0 x4 via CPU, M.2_2 PCIe 4.0 x4 & M.2_3 PCIe 4.0 x2 via Chipset)
• SATA Ports: 4x SATA 6Gb/s
• RAID Support: RAID 0, 1, 5, 10 for SATA storage devices

• Power: 1x 24-pin ATX, 2x 8-pin CPU, 1x 8-pin PCIe (Supplemental)
• Front USB: 1x Type-C 10Gbps, 4x Type-A 5Gbps, 4x USB 2.0
• Cooling/RGB: 1x CPU Fan, 1x Pump Fan, 4x System Fan, 1x EZ Conn-header, 2x ARGB V2, 1x RGB LED
